存储区

描述

定时器

T0到T2047

计数器

 Z0到Z2047

标志位

标志位存储区 131.072 位 (16 KB)

总输入输出寻址存储区

输入输出存储区 262.136位 (32 KB)

过程映像区(可调整；每个循环更新)

最大： 131.072 位 (16 KB)
默认设置： 131.072位 (16KB)

本地数据 (可调整)

最大： 32 KB
默认设置： 32 KB

数据块

2048 功能块 (FB) 和功能 (FC) 最大数：65534
4095数据块(DB)最大长度：65570

系统功能块(SFBs)

SFB0, SFB1, SFB2, SFB3, SFB4, SFB5, SFB8, SFB9, SFB12, SFB13, SFB14, SFB15, SFB19, SFB20, SFB22, SFB23, SFB31, SFB32, SFB33, SFB34, SFB35, SFB36, SFB37, SFB52, SFB53 and SFB54

系统功能 (SFCs)

SFC0, SFC1, SFC2, SFC3, SFC4, SFC5, SFC6, SFC9, SFC10, SFC11, SFC12, SFC13, SFC14, SFC15, SFC17, SFC18, SFC19, SFC20, SFC21, SFC22, SFC23, SFC24, SFC26, SFC27, SFC28, SFC29, SFC30, SFC31, SFC32, SFC33, SFC34, SFC36, SFC37, SFC38, SFC39, SFC40, SFC41, SFC42, SFC43, SFC44, SFC46, SFC47, SFC49, SFC50, SFC51, SFC52, SFC54, SFC55, SFC56, SFC57, SFC58, SFC59, SFC62, SFC64, SFC78, SFC79, SFC80, SFC82, SFC83, SFC84, SFC85, SFC87, SFC90, SFC105, SFC106, SFC107 and SFC108
 对于SFC26 and SFC27来说0是唯一支持的输入参数。

组织块(OBs)

OB1 (free cycle)
OB10 to OB17 (time-of-day interrupt)
OB20 to OB23 (delay interrupt)
OB30 to OB38 (cyclic interrupt)
OB40 to OB47 (process alarm)
OB55 (status interrupt)
OB56 (interrupt update)
OB57 (manufacturer-specific interrupt)
OB60 (multiprocessor interrupt)
OB61 to OB64 (synchronous cycle interrupt)
OB65 (Technology synchronization interrupt)
OB70 (IO redundancy error)
OB72 (CPU redundancy error)
OB73 (communication error)
OB80 (time error)
OB82 (diagnostics interrupt)
OB81 (power supply failure)
OB83 (remove/plug alarm)
OB84 (CPU hardware error)
OB85 (program execution error)
OB86 (subrack failure)
OB87 (communication error)
OB88 (processing alarm)
OB90 (background OB)
OB100 (restart)
OB101 (hot restart)
OB102 (cold restart)
OB121 (programming error)
OB122 (IO access error)
